Coming soon
Wireless DMX light controller
Your lights, on the beat.
Azanur listens to the music straight from the mixer, finds the tempo and the drop, and drives your PARs, moving heads and effects over DMX. You control everything from your phone. No app to install, no laptop on the booth.
8 + 8
PAR lights + moving heads / effects
16
scenes stored on the device
40 fps
steady DMX512 output
≈ 1 W
typical power draw
Signal path
One box between the mixer and the lights
Audio in
Mixer line out
Booth, Rec or Aux output. No microphone, so a loud room does not confuse it.
Azanur
Beat, tempo, drop
Counts BPM from the kick drum only, detects build-ups and drops, and renders effects for every fixture.
DMX out
Wired and wireless
XLR output for cabled fixtures, built-in 2.4 GHz wireless DMX transmitter for the rest.
Features
Built for a full night, run from a phone
Rhythm mode
Lights pulse on the beat. Auto, Soft and Punchy styles; the Auto style follows the energy of the track. A base level keeps the room from going dark between hits.
Drop detection
When the kick drops out after an energetic part, the lights build up faster and brighter. When it comes back: white impact, strobe and a fast chase.
Fade mode
A colour wheel locked to the tempo, over 32, 16 or 8 bars, with adjustable colour spread between fixtures.
Manual colour
Pick colours per fixture with a colour wheel, hue or RGB sliders, plus amber and UV. Save up to 8 favourite colours on the device.
Moving heads and effects
Movement patterns synced to the BPM, mirrored left and right. Gobos and colours change on the beat, the prism kicks in on energetic parts.
Scenes
Up to 16 named scenes with crossfade. After power-up it restores exactly where you left off.
Flash, Strobe, Blackout
Hold-to-fire buttons that work from any mode. If the phone disconnects, they release on their own after 1.5 s.
No app needed
Join the Wi-Fi and the controller opens by itself. Up to 5 phones at once, with a clean interface made for dark rooms.
Updates over Wi-Fi
New firmware downloads from the cloud through any internet Wi-Fi or phone hotspot, or from a file. No cable, no computer.
- PAR / Uplight
- Spot
- Beam
- Wash
- Scanner
- Gobo
- Derby
- Laser
- Strobe
- Fog machine
Each fixture type gets its own controls, and they only appear once that fixture is added. Channel maps are editable to match any fixture’s manual.
The interface
Everything from your phone
Technical specifications
Power and specs
Power input
12 V DC
Accepts 6–24 V DC, barrel jack 5.5 × 2.1 mm, centre positive
Typical consumption
≈ 1 W
≈ 85 mA at 12 V, with Wi-Fi and wireless DMX active
Peak consumption
≈ 2.5 W
Short Wi-Fi transmit bursts. A 12 V / 1 A adapter leaves plenty of headroom.
DMX
| Protocol | DMX512, 1 universe |
| Outputs | XLR (wired) + 2.4 GHz wireless DMX |
| Refresh rate | 40 fps |
| Timing | BREAK 150 µs · MAB 16 µs |
| Fixtures | 8 PAR (up to 32 ch each) + 8 moving heads / effects |
Audio
| Input | Line level from the mixer |
| Analysis | Beat, BPM, energy, drop |
| Without music | Tap tempo and internal metronome |
Control
| Wireless | Wi-Fi 2.4 GHz, own network |
| Phones at once | up to 5 |
| Interface | Any browser, opens automatically |
| Address | 192.168.4.1 |
| Firmware | v2.6, updates over Wi-Fi |
Memory
| Scenes | 1–16, named |
| Custom colours | 8 |
| Power loss | Restores the last state |
Power figures are estimates for the current hardware revision and will be confirmed by measurement.
Enclosure
Small enough for any booth
187 × 106 × 45 mm
| Material | 3D-printed PETG, matte black |
| Top | Clean, no visible screws, logo inlay |
| Rear panel | DC power, Audio In, DMX Out, antenna |
| Feet | 4 rubber feet |
Availability
Coming soon
Azanur is in its final testing phase. The first units will be available soon.
